Eaton xPole PXL, S200 MCB, 3P, 50A Curve C, 400V AC, 48V DC, 10 kA Breaking Capacity - 236431 PXL-C50/3

Number of Poles = 3
Current Rating = 50A
Tripping Characteristics = Type C
Rated AC Voltage = 400V
Rated DC Voltage = 48V
Breaking Capacity at Maximum Voltage Rating = 10 kA
Range = xPole
Series = PXL, S200
Circuit Breaker Type = MCB
Length = 52.5mm
Mounting Style = DIN Rail Mount
Depth = 60mm

IEC / EN 60898. PXL series, C characteristic, 3-pole. Circuit breaker with high selectivity as a pre-fuse with low passband energy Bus bar compatible With double terminal, lift / jaw top and bottom Free selection of rail arrangement top and bottom Finger-proof / back-of-hand-proof Quick-fit action with 3 locking positions for top-hat rail IEC / EN 60715
