The Mega Anchor Connector by Douglas Marine is a high-quality, rotating stainless steel junction designed to securely link your anchor to the chain, enhancing the safety and stability of your anchorage. Crafted from polished AISI 316 stainless steel, it offers exceptional resistance to corrosion and wear, ensuring longevity and reliability.
- Rotating Design: Prevents the shackle from jamming or getting caught, facilitating smooth retrieval through the bow roller.
- Seamless Connection: Eliminates protrusions, allowing for a direct link between the anchor and chain without the need for additional shackles.
- Enhanced Strength: Built to withstand high loads, providing robust support for your anchoring system.
Technical Specifications:
- Suitable Anchor Weight: 50 to 80 kg
- Chain Diameter Compatibility: 14 to 16 mm
- Dimensions:
- Length (H): 176 mm
- Width (B): 35 mm
- Height (G): 36 mm
- Pin Diameter (P): 18 mm
- Chain Diameter (C): 20 mm
- Breaking Load: 26,000 kg
- Weight: 3.5 kg
Materials:
- Construction: Polished AISI 316 stainless steel
Compatibility Information:
- Anchor Weight: Suitable for anchors weighing between 50 to 80 kg
- Chain Diameter: Compatible with chains ranging from 14 to 16 mm in diameter
