The Master Mooring Junior Mooring Device is an innovative and secure mooring system designed for boats weighing between 9 and 13 tonnes. This device offers a reduced size—approximately 25% smaller—while maintaining the same breaking load as comparable products on the market. Constructed from high-resistance (HR) stainless steel and specially engineered elastomers, it ensures exceptional durability and performance. The device is equipped with an anti-retention end stop, and its special heads induce perfect axiality during compression, enhancing its longevity. It is guaranteed to withstand over 400,000 cycles at maximum compression, providing progressive and silent damping for optimal mooring stability.
- Innovative and secure mooring system for boats up to 13 tonnes
- Approximately 25% smaller size compared to similar products
- Constructed from high-resistance stainless steel and specially engineered elastomers
- Equipped with an anti-retention end stop
- Special heads induce perfect axiality during compression
- Guaranteed to withstand over 400,000 cycles at maximum compression
- Provides progressive and silent damping
Technical Specifications
- Boat Weight: 9-13 tonnes
- Working Load: 7,000 kg
- Elastic Capacity: 250 kg
- Spring Ride (Extension): 120 mm
- Breaking Load: 15,000 kg
- Dimensions: 85 mm (diameter) x 420 mm (length)
- Weight: 2.3 kg
Materials
- Main Body: High-Resistance Stainless Steel
- Elastomers: Specially Engineered for Enhanced Durability
Dimensions
- Diameter: 85 mm
- Length: 420 mm
- Extension (Spring Ride): 120 mm
Compatibility Information
Suitable for boats with a displacement between 9 and 13 tonnes. For boats outside this range, refer to other models in the Master Mooring Series:
- For boats from 7 up to 9 tonnes: Master Mooring Series Junior (Code: 806-0017)
- For boats from 13 up to 17 tonnes: Master Mooring Series Junior (Code: 806-0019)
- For boats from 17 up to 20 tonnes: Master Mooring Series Junior (Code: 806-0019PLUS)
