- Key Features:
- Designed for marine applications, offering exceptional corrosion resistance in harsh environments, including seawater exposure.
- Features a black elastomer coating that provides UV protection and ensures a perfect seal without the need for additional sealing joints.
- Easy installation with no need for sealing joints, enhancing aesthetic appeal.
- Suitable for various fixations such as stays, lifelines, and pulleys.
- Technical Specifications:
- Material: Stainless Steel 316L
- Elastomer Coating: Black UV-treated elastomer
- Diameter: 8 mm
- Length: 80 mm
- Working Load: 2,400 kg
- Breaking Load: 4,800 kg
- Maximum Tightening Torque: 18 Nm
- Weight: 123 g
- Dimensions:
- A: 36 mm
- B: 25 mm
- C: 40 mm
- Materials: Constructed from high-quality stainless steel 316L for enhanced durability and resistance to corrosion.
- Dimensions: Diameter of 8 mm and length of 80 mm, with specific dimensions A (36 mm), B (25 mm), and C (40 mm) for precise installation.
- Compatibility Information: Ideal for marine applications requiring secure and corrosion-resistant fixations, including stays, lifelines, and pulleys.
- Additional Details:
- The elastomer coating not only provides UV protection but also ensures a perfect seal, eliminating the need for additional sealing joints.
- The product is delivered with locks and a counterplate for secure installation.
