Key Features:
- Designed for use with various socket types, excluding Entre-Prises.
- Sold individually.
Technical Specifications:
- Thread Size: M10 (10 mm)
- Length: 60 mm
- Thread Pitch: 1.5 mm
- Head Style: Socket Head Cap
- Material: Stainless Steel A2
- Finish: Natural
- Manufacturing Standard: ISO 7380
- Socket Size: 6 mm
- Head Diameter: 17.5 mm
- Head Height: 5.5 mm
- Captive Diameter: 8 mm
- Captive Length: 40 mm
- Hexagon Depth: 3.12 mm
- Thread Length: 20 mm
- Countersunk Angle: 90 Degrees
- Countersunk Length: 5.5 mm
Materials: High-quality stainless steel (A2) for enhanced durability and resistance to corrosion.
Dimensions:
- Thread Size: M10 (10 mm)
- Length: 60 mm
- Head Diameter: 17.5 mm
- Head Height: 5.5 mm
- Captive Diameter: 8 mm
- Captive Length: 40 mm
- Hexagon Depth: 3.12 mm
- Thread Length: 20 mm
- Countersunk Angle: 90 Degrees
- Countersunk Length: 5.5 mm
Compatibility Information: Suitable for use with various socket types, excluding Entre-Prises.
Additional Details:
- Manufactured according to ISO 7380 standards.
- Features a captive design with a 90-degree countersunk angle for secure fastening.
- Natural finish provides a clean appearance and resistance to corrosion.
