Crouzet Plunger Limit Switch, NO/NC, IP66, IP67, Metal Housing, 30V ac Max, 100mA Max - 83872301

Actuator Type = Plunger
Normal State Configuration = NO/NC
IP Rating = IP66, IP67
Maximum Current = 100mA
Housing Material = Metal
Maximum AC Voltage = 30V
Maximum DC Voltage = 30V
Connection Type = Cable
Action Type = Snap Action
Length = 49mm
Depth = 16mm
Mechanical Life = 10000000Cycles

UL508. Dimensions refer to limit switch body only. Compact Limit Switch with Low Level Cable Output Short Travel Series. Short travel series of Limit Switches, metal cased limit switches complete with fitted 5 core 0.75mm ;sup>2 ;/sup> 7.3mm ext. dia.cable, four terminal double break two-way contact elements.The 2 moving contacts are electrically isolated from one another. Impulse voltage 2500V Insulation voltage 250V Operating voltage 4 to 30V Operating current 1 to 100mA 1 metre cable length Temperature range -25 to +70 deg C 20mm pitch mounting holes IP66/67
