Crouzet Lever Limit Switch, NO/NC, IP66, IP67, Metal Housing, 30V ac Max, 100mA Max - 83873301
Reliable Crouzet limit switch with IP66/IP67 rating and compact design for versatile applications.
Manufacturer part number: 83873301
Only Ships to: France, Monaco For shipping outside these regions, please contact customer support.
UL508. Dimensions refer to limit switch body only. Compact Limit Switch with Low Level Cable Output Short Travel Series. Short travel series of Limit Switches, metal cased limit switches complete with fitted 5 core 0.75mm ;sup>2 ;/sup> 7.3mm ext. dia.cable, four terminal double break two-way contact elements.The 2 moving contacts are electrically isolated from one another. Impulse voltage 2500V Insulation voltage 250V Operating voltage 4 to 30V Operating current 1 to 100mA 1 metre cable length Temperature range -25 to +70 deg C 20mm pitch mounting holes IP66/67
