Crouzet Lever Limit Switch, NO/NC, IP66, IP67, Metal Housing, 240V ac Max, 6A Max - 83873101
Durable Crouzet lever limit switch with IP66/67 rating and metal housing for reliable performance.
Manufacturer part number: 83873101
GTIN: 3593150038285
Only Ships to: France, Monaco For shipping outside these regions, please contact customer support.
Actuator Type = Lever
Normal State Configuration = NO/NC
IP Rating = IP66, IP67
Maximum Current = 6A
Housing Material = Metal
Maximum AC Voltage = 240V
Maximum DC Voltage = 125V
Connection Type = Cable
Action Type = Snap Action
Length = 76.6mm
Width = 30mm
UL508, UL50. Dimensions refer to limit switch body only. Compact Metal Limit Switch with Cable Output. Metal cased limit switches complete with fitted 5 core 0.75mm ;sup>2 ;/sup> 7.3mm ext. dia.cable and four terminal double break two-way contact elements with positive opening contacts which are electrically isolated from one another. Impulse voltage 2500V Insulation voltage 500V Thermal Current (Ith) 10A Minimum load switching voltage 10V Minimum load switching current 10mA Temperature range -25 to +70 deg C Minimum current switching load 100mA 1 Metre cable length 20mm pitch mounting holes IP66/67
