Key Features:
- Designed for solvent cement jointing of PVC-U pipes.
- Suitable for potable water supply, irrigation, swimming pool networks, and chemical and food industries.
- Complies with EN 1452-3 standards.
- Equipped with an EPDM O-ring to ensure watertightness without the need for PTFE tape.
Technical Specifications:
- Material: PVC-U
- Pressure Rating: 10 bar
- Operating Temperature Range: 0°C to 60°C
- Standards Compliance: EN 1452-3
Materials:
- Body: PVC-U
- O-Ring: EPDM
Dimensions:
- Outer Diameter: 33.2 mm
- Length: 42.5 mm
- Socket Depth: 16 mm
- Thread Size: 21.2 mm
- Thread Length: 22.6 mm
- O-Ring Diameter: 15.4 mm
Compatibility Information:
- Compatible with 16mm PVC pressure pipes and spigot fittings.
- Not compatible with imperial PVC pressure pipes or fittings.
Additional Details:
- To ensure a secure joint, it is recommended to apply a PVC primer before using solvent cement.
- PTFE tape or sealants are not recommended for plastic-to-plastic connections.
- Not suitable for use with compressed air or gas.
