This unipolar magnetic switch, with a fully flat actuator in the ON position, is designed to ensure maximum safety in marine installations. Being flush when connected minimizes the risk of accidental disconnection, crucial in boat electrical panels exposed to vibrations or frequent handling.
Technical Features
- Type: Magnetic, unipolar (1P)
- Shape: Flat actuator for maximum protection
- Electrical capacity: 20A DC, 32A AC, up to 240V
- Mounting: Panel mount
- Manufacturer reference: Carling Technologies BS7404
Advantages
- Prevents accidental disconnections
- High reliability against marine vibrations
- Long service life even in saline environments
Recommended Applications
- Protection of main boat circuits
- Critical points in the electrical panel
Installation and Maintenance
- Professional installation recommended
- Check actuator adjustment and cleanliness every season
Materials and Quality
- Made with corrosion-resistant materials (for more details, consult Carling Technologies datasheet)
| Characteristic | Value |
|---|
| Maximum current | 20A DC, 32A AC |
| Maximum voltage | 240V |
| Actuator type | Flat |
| Poles | 1P unipolar |
