Key Features:
- Quick-connect design for efficient and secure fluid transfer.
- Constructed from durable 316 stainless steel for enhanced corrosion resistance.
- Compatible with other MIL-C-27487F standard camlock fittings.
- Equipped with an NBR (nitrile rubber) seal for leak prevention.
- Maximum operating pressure of 150 PSI.
- Suitable for temperatures ranging from -10°C to +80°C.
Technical Specifications:
- Camlock Size: 1/2 inch (15 mm)
- Threaded Connection: 1/2 inch Male NPT (National Pipe Tapered)
- Material: 316 Stainless Steel
- Seal Material: NBR (Nitrile Rubber)
- Maximum Operating Pressure: 150 PSI
- Temperature Range: -10°C to +80°C
Materials:
- Body and Cam: 316 Stainless Steel (EN 1.4408)
- Seal: NBR (Nitrile Rubber)
Dimensions:
- Male Outside Diameter: 15/16 inch (0.9375 inches or 23.81 mm)
Compatibility Information:
- Designed to connect with 1/2 inch female camlock couplings.
- The male threaded side connects to 1/2 inch female NPT threads.
- Not suitable for compressed air or steam applications.
Additional Details:
- Camlock fittings are widely used in industries such as chemical, petroleum, and food processing for their ease of use and secure connections.
- Ensure compatibility with other fittings before use.
