Key Features:
- Self-Priming Capability: Designed for efficient self-priming, capable of lifting water containing air or other gases.
- Built-in Ejector: Equipped with a built-in ejector for enhanced performance.
- High-Quality Construction: Features a stainless steel casing and a brass alloy impeller, minimizing the use of plastic materials.
- Environmental Considerations: Constructed with environmental sustainability in mind.
Technical Specifications:
- Flow Rate: Up to 60 liters per minute (3.6 cubic meters per hour).
- Maximum Head: Up to 50 meters.
- Power Output: 0.65 kW (0.9 HP).
- Voltage: Three-phase 230/400 V ± 10%.
- Motor Speed: 2800 RPM.
- Suction Port: 1 inch (25 mm).
- Delivery Port: 1 inch (25 mm).
- Maximum Suction Lift: 9 meters.
- Maximum Liquid Temperature: 35°C.
- Protection Class: IP 54.
- Insulation Class: Class F.
- Motor Efficiency: High-efficiency three-phase motor IE3 from 0.75 to 1.50 kW.
Materials:
- Pump Casing: Stainless steel.
- Impeller: Brass alloy.
- Diffuser and Ejector: Noryl.
- Shaft: Stainless steel 430.
- Mechanical Seal: Carbon ceramic/NBR.
Compatibility Information:
- Voltage Compatibility: Suitable for three-phase 230/400 V ± 10% electrical systems.
- Temperature Range: Operates effectively with liquids ranging from 0°C to 35°C.
Additional Details:
- Applications: Ideal for water supply from wells, lifting water containing air or gases, increasing water pressure from flooded suction applications, pressure boosting for central water systems with low pressure (following local specifications), gardening, and washing with a water jet.
- Certifications: Drinking water certificate available.
- Motor Protection: Equipped with thermal protection.
- Installation: Designed for horizontal installation.
