Selector panel specially designed for 230V AC systems up to 32 amps, essential for managing and selecting various electrical sources onboard.
Technical Features
- Rated voltage: 230V AC
- Maximum current: 32A
- Switches: 2 double with sliding safety lock
- Dimensions: 95 x 133 mm
- Prevents dangerous connections between generator and ground.
Advantages
- Allows reliable switching between two sources (e.g., generator and ground) without risk of simultaneous connection.
- Mechanical lock that enhances energy management safety.
- Compact design and easy integration into standard electrical panels on boats.
Applications
- Manual source selection in medium-high capacity electrical systems, both yachts and professional vessels.
- Use in AC installation modernization projects onboard.
Installation Advice
- Installation recommended by qualified technical personnel.
- Verify correct circuit identification and correspondence to the selector panel.
Maintenance and Safety
- Periodically check the locking mechanism to avoid faults caused by intensive use.
- Disconnect power supply before any panel intervention.
Specification Table
| Rated voltage | 230V |
|---|
| Maximum current | 32A |
|---|
| Switches | 2 double with lock |
|---|
| Dimensions | 95 x 133 mm |
|---|
| Brand | Blue Sea |
|---|
