This electrical panel is designed for outdoor or flybridge installation, offering centralized control of up to 8 independent circuits on your vessel, thanks to its integrated switches and circuit breakers.
Technical Features
- Configuration: 8 horizontally arranged switches
- Material: Anodized anticorrosion aluminum
- Illuminated switches and 15A circuit breakers
- Max total current: 45A
- Supported voltage: 12V (20A), 24V (15A)
- Easy mounting outdoors and on flybridge
- Brand: Blue Sea
- Reference: BS8271
Advantages
- High environmental resistance (salt air and UV rays)
- Protects each line with individual circuit breakers
- Easy night identification and handling thanks to integrated lighting
- Aesthetic suited to high-end vessels
Usual Applications
- Control of bilge pumps, lighting, windlasses, navigation equipment, etc.
- Main or secondary panel on yachts, sailboats, and launches
Installation Tips
- Install in accessible and impact-protected areas
- Select protections according to the load of each circuit
- Carry out periodic inspections of circuit breakers
Maintenance
- Periodically clean with products suitable for aluminum
- Check connections and tightening
- Replace switches if lighting failures occur
Specification Table
| Switches | 8 |
|---|
| Type | 15A Circuit breakers |
|---|
| Maximum total current | 45A |
|---|
| Voltage | 12V (20A), 24V (15A) |
|---|
| Material | Anodized aluminum |
|---|
