Binder Circular Connector, 16 Contacts, Panel Mount, M16 Connector, Socket, Female, IP40, 680 Series - 09-0340-00-16

Number of Contacts = 16
Mounting Type = Panel Mount
Connector Size = M16
Plug/Socket = Socket
Contact Gender = Female
Termination Method = Solder
IP Rating = IP40
Current Rating = 3.0A
Series = 680
Voltage Rating = 60.0 V
Shell Size = 20
Housing Material = Metal
Contact Plating = Gold
Minimum Operating Temperature = -40°C

Panel plug ; socket. Featuring a straight body, this panel mount connector is miniature but robust. Ideal for solder termination it features silver contact plating with brass contact material. Binder 680 series connectors provide high reliability with simple assembly. Common use for these connectors include medical equipment, machine tool control, industrial automation and instrumentation. Features and Benefits:. The use of Silver and Brass prevent oxidation and therefore provide durability and extend life expectancy. Multiple termination techniques are available due to the miniature size for panel mounting. Additional features:. • Female • Solder termination • Operating temperature -40°C to +85°C
