Amphenol Limited, 62GB 4 Way Cable MIL Spec Circular Connector Plug, Socket Contacts,Shell Size 8, Bayonet, - 62GB-56T08-04PN-760
Reliable 4-way MIL Spec circular connector with bayonet mating for secure connections.
Manufacturer part number: 62GB-56T08-04PN-760
Availability: Out of stock
Only Ships to: France, Monaco For shipping outside these regions, please contact customer support.
Number of Contacts = 4
Gender = Male
Contact Gender = Female
Current Rating = 7.5A
Voltage Rating = 850 V
Shell Size = 8
Mounting Type = Cable
Military Standard = MIL-DTL-26482
Mating Type = Bayonet
Body Orientation = Straight
Series = 62GB
The Amphenol 62GB series connector brings the advantage of keyway orientation to reduce mismating around multiple connectors. They feature aluminium shells with brass or stainless steel options available. A resilient neoprene insulator integrated rear wire sealing grommet guarantees a liquid tight assembly.Temperature operating range : -55°C to 125°C Wire gauges and current carrying capabilities : Upto 45A and size 24 to 8 AWG wires Connectors contacts are gold plated
