Amphenol Industrial, Surlok Plus RADSOK EV Connector Plug, 300A - SLPPC70BSB1 / C10-730190-1701

Number of Rows = 1
Number of Contacts = 1
Wire Size = 70 mm²
Operating Voltage = 1000V
Connector Gender = Male
Orientation = Right Angle
Colour = Black
Pin Diameter = 10.3mm

10.3mm SurLok Plus Plug for 70mm (180 Key). From Amphenol, this SurLok Plus series plug is a compact and quick mating compression lug that features a quick lock and press-to-release connection. Robust and environmentally sealed, the plug is field installable and highly reliable. With R4 Radsock technology, the connection assures a high tensile strength connection with a highly conductive surface area. The plug has a 10.3mm pin and terminates to 70mm² wires. Features and Benefits. • Plug rotates 360° • Touch Proof • Spring Locking • Keyed to prevent mismating (180 degree) • IP67 • Flammability rating of UL 94-V0. Applications. SurLok Plus series connectors are often used in Electric Vehicle applications (EV/HEV) and rail mass transit. The series also has applications in process control, medical and BMS/Energy storage.
