Allen Bradley Guardmaster 440H Hinge Switch, NO/2NC - 440H-R03079

Range = Rotacam
Series = 440H
Lock Style = Hinge
Normal State Configuration = NO/2NC
Shaft Length = 85mm

these are not to be used for load bearing applications. Allen-Bradley Rotacam Hinge Switch. The Rotacam is heavy-duty, hinge-actuated safety-interlock switch. It can be used as, or connected to, the existing hinge pin for direct operation of the switch. Machine power is isolated when the guard has been opened just 5°. For applications requiring a larger degree of operation, the internal cam can be adjusted from 5…11°. Can be used as a hinge pin on light and medium weight guard doors Isolates power within 5° of door movement (2° to operate 2N/C safety contacts, 3° to operate 1N/O auxiliary - which can be used to indicate which guard has been opened, or can operate an alarm) Degree of operation can be customized with adjustable cam Robust die-cast case, ideal for heavy-duty applications Contacts 2 NC ; 1 NO Forced guided contacts - complies with EN 1088, IEC 947-5-1
