Allen Bradley 100S-C Contactor, 24 V dc Coil, 3-Pole, 30 A, 2NO + 2NC, 690 V ac - 100S-C30EJ22C

Coil Voltage = 24 V dc
Number of Poles = 3
Contact Voltage Rating = 690 V ac
Contact Current Rating = 30 A
Series = 100S-C
Function = Safety
Normal State Configuration = 2NO + 2NC
Auxiliary Contact Configuration = 2NO + 2NC
Length = 81mm
Depth = 143mm
Maximum Operating Temperature = +60°C

DC versions incorporate a diode protection circuit. 100S-C, 3 Pole Safety Contactors 2N/O ; 3N/C. The Bulletin 100S-C safety contactors provide mechanically linked positively guided contacts, required in feedback circuits of modern safety applications. The mechanically linked N.C. auxiliary contacts will not change state when a power pole welds. In addition, the gold-plated bifurcated auxiliary contacts are ideally suited for low-energy applications or feedback control circuits with multiple series-connected N.C. auxiliary contacts. Redundant contactors to isolate motor (hazardous motion) Positively guided main contacts Red contact housings for easy identification as safety device Protective cover prevents manual operation - yet the window allows visible ON/OFF status
