The brass main disconnect switch, equipped with a large lever and chain, is a robust option to isolate the main electrical circuit on your boat.
Technical Features
- Current capacity: 250A indicative (confirm exact capacity with manufacturer if critical)
- Brass body and high-resistance, anti-corrosion plastic composite
- Copper contacts for excellent electrical conductivity
- Operating mechanism with removable lever secured by chain
- Protective cover to prevent dust and salt ingress
- Dimensions: 134 x 134 x 77 mm
Advantages
- Safe power cut-off for maintenance work, extended anchoring, or winter storage
- Durable materials for prolonged use in marine environments
- Removable lever adds security against unauthorized use
Applications
- Suitable for recreational, work, and professional boats
- Recommended to install near the main battery for maximum effectiveness
Installation and Use
- Mount on a solid surface, preferably away from direct moisture
- Secure all connections according to marine standards
Maintenance
- Check the condition of contacts and clean periodically to prevent corrosion
| Max. current | 250A* |
|---|
| Body material | Brass and anti-corrosion plastic |
|---|
| Contacts | Copper |
|---|
| Dimensions | 134 x 134 x 77 mm |
|---|
| Lever | Removable with chain and cover |
|---|
*Indicative capacity, confirm specific requirements if for critical use.
