Telemecanique Sensors Inductive Block Proximity Sensor, 40 mm Detection 4-20 mA, 24 V dc - XSDH603629

The Schneider Electric XS series inductive proximity sensor is solely for the detection of metal objects. It basically comprises an oscillator whose windings constitute the sensing face. An alternating magnetic field is generated in front of these windings. When a metal object is placed within the magnetic field generated by the sensor, the resulting currents induced form an additional load and the oscillations cease. This causes the output driver to operate and, depending on the sensor type, a normally open (NO) or normally closed (NC) output signal is produced.Detection face Frontal Detector flush mounting acceptance Non flush mountable Material Plastic Front material Plastic Output circuit type DC Analogue output range 4..20 mA Cable entry 1 entry tapped for Pg 13.5 cable gland Switching capacity in mA <= 20 mA
