Telemecanique Sensors ATEX XCSB Safety Interlock Switch, 2NO/1NC, Keyed, Zinc Alloy - XCSB502EX

Lock Style = Keyed
Normal State Configuration = 2NO/1NC
Maximum AC Voltage = 240V
Maximum DC Voltage = 250V
Connection Type = M20
Housing Material = Zinc Alloy
Range = Preventa
IP Rating = IP67
Hazardous Area Certification = ATEX
Number of Head Directions = 8
Series = XCSB
Length = 113.5mm

II 2 D – Ex tD A21 IP67 T90C°. Actuators must be purchased separately, see ; 252-3836 252-3836 etc. XCSB Hazardous Area Unlocking by Pushbutton. Metallic guard switches that can be used in potentially explosive dusty environments for safety applications. Manual locking/unlocking of actuator by pushbutton operated lock Zones 21-22 Protection mode tD Suitable for Category 4/PLe circuits (EN ISO 13849-1) Screw clamp terminals Dimensions: 52 x 44 x 113.5mm
