RS PRO Straight, Panel Mount, Socket to Socket Type Micro AB to Micro AB IP67 USB Connector - 1359769

Gender = Female to Female
Mounting Type = Panel Mount
Termination Method = Plug In
IP Rating = IP67
Current Rating = 1.0A
Voltage Rating = 100.0 V
Series = GTC Sealed
Contact Material = Copper Alloy
Minimum Operating Temperature = -40.0°C
Maximum Operating Temperature = +105°C

RS PRO USB Connector, Panel Mount, Plug A, B A, B, Plug In, Straight IP67Need a reliably waterproof micro USB to micro USB connector? Manufactured from rugged thermoplastic with a black silicone gasket providing a tight panel seal, this coupler from the RS PRO range is effective at keeping out water and dust. It has an IP67 rating, which means its waterproof at a depth of a metre for half an hour. This connector is recommended for panels between 0.8 mm and 3.0 mm thick. Contacts are gold-plated to ensure quality data transmission. Its voltage-rated at 100 V, current-rated at 1 A and has an operating temperature range of -40°C to +105°C. Straight orientation makes for easy installation. This connector has been tested against international standards to ensure it wont damage equipment via electrostatic discharge (ANSI/ESD S20.20:2014 and BS EN 61340-5-1:2007). Its also compliant with RoHS (Restriction of Hazardous Substances) standards. Youll find this kind of connector used in outdoor displays or in the marine and military sectors.Features and Benefits• USB to micro USB connector • Panel mount • Recommended panel thickness 0.8 mm to 3 mm • GTC sealed • Minimum operating temperature of -40°C • Maximum operating temperature of +105°C • Voltage rated at 100 V • Current rated at 1 A • Gold-plated contacts ensure quality data transmission • RoHS compliant on hazardous substances • Compliant with ANSI/ESD S20.20:2014 and BS EN 61340-5-1:2007 electrostatic standardsRS PRORS PRO is our own brand range and brings you a wide range of high-quality, great value products offering you more choice. Trusted by engineers all over the world, every part of every RS PRO product has been rigorously tested against demanding industry standards they’re only given the RS PRO Seal of Approval if we’re confident of their exceptional quality, which means you can be confident too.
