Panasonic PCB Mount Power Relay, 24V dc Coil, 48A Switching Current, SPST - HE1AN-P-DC24V-Y5
High capacity PCB mount power relay from Panasonic, featuring a 24V dc coil and 48A switching current.
Manufacturer part number: HE1AN-P-DC24V-Y5
Only Ships to: France, Monaco, Italy For shipping outside these regions, please contact customer support.
Coil Voltage = 24V dc
Contact Configuration = SPST
Mounting Type = PCB Mount
Switching Current = 48A
Number of Poles = 1
Latching = No
Terminal Type = Through Hole
Length = 38mm
Coil Resistance = 300O
Coil Power = 1.92W
Height = 36.3mm
Maximum Switching Power AC = 23.52 kVA
Ul; SCA; VDE; TUV. HE Series. These PCB mount power relays have a high capacity and long life and offer excellent surge resistance. Typical applications for these PCB power relays include office equipment, industrial equipment and home appliances. High capacity and long life Single side stable type Surge voltage more than 10,000V Excellent resistance to contact welding due to the pre-tension and kick-off mechanism Typical applications: Machine tools, Moulding equipment, Air conditioners, Heating equipment
