Mitutoyo Skidded Transverse Tracing Drive Unit Type Detector, 360µm Measuring Range, for use with Surftest SJ-210 - 178-565-11E
Achieve precise roughness measurements with the Mitutoyo Skidded Transverse Drive Unit for Surftest SJ-210.
Manufacturer part number: 178-565-11E
Availability: Out of stock
Only Ships to: France, Monaco For shipping outside these regions, please contact customer support.
Roughness Tester Accessory Type = Transverse Tracing Drive Unit Type Detectormm
Measuring Speed = 0.5 mm/s, 0.25 mm/s
Range = 360µm
Measuring Force = 0.75mN
Stylus Type = Diamond Tip
Roughness Standard = ANSI, ISO 97, JIS 01, JIS 82, JIS 94, VDA
Plug Type = Type G - British 3-pin
Power Source = Battery, Mains
Skidded/Skidless = Skidded
Stylus Tip Radius = 2µm
Stylus Tip Angle = 60°
For Use With = Surftest SJ-210
