SMC Pneumatic Piston Rod Cylinder - 25mm Bore, 100mm Stroke, CU Series, Double Acting - CDU25-100D
Compact and efficient SMC pneumatic cylinder with 25mm bore and 100mm stroke for versatile applications.
Manufacturer part number: CDU25-100D
Only Ships to: France, Monaco For shipping outside these regions, please contact customer support.
Manufacturer Series = CU
Bore = 25mm
Port Connection = M8
Cushioning Type = Rubber Bumper
Dimensions = 173 x 50 x 32mm
Length = 173mm
Absolute Maximum Pressure = 1.05MPa
Minimum Operating Temperature = -10°C
Bore sizes from 6mm to 32mm available Stroke lengths up to 100mm Any surfaces can be used for mounting Space saving Auto-switch capable
