SKF 4309 ATN9 Double Row Deep Groove Ball Bearing- Open Type 45mm I.D, 100mm O.D
High-performance SKF double row deep groove ball bearing for versatile applications.
Manufacturer part number: 4309 ATN9
GTIN: 7316577004611
Availability: Out of stock
Only Ships to: France, Monaco For shipping outside these regions, please contact customer support.
Inside Diameter = 45mm
Outside Diameter = 100mm
Race Width = 36mm
Ball Bearing Type = Double Row Deep Groove Ball Bearing
Sealing Arrangement = Open Type
Bearing Clearance = CN
Material = Steel
Ball Material = Steel
Cage Material = Non-metallic
Number of Rows = 2
Static Load Rating = 56kN
Dynamic Load Rating = 68.9kN
Bore Type = Parallel
Bearing Series = 3 Medium
Partial Bearing Code = 4309
The SKF deep groove ball bearings are particularly versatile. They are suitable for high and very high speeds, accommodate radial and axial loads in both directions and require little maintenance. Because deep groove ball bearings are the most widely used bearing type, they are available from SKF in many designs, variants and sizes. It has 45 mm ID and 100 mm OD.Bearing material is of bearing steel Cylindrical bore type
