Schneider Electric Acti 9 A9N1 MCB, 2P, 63A Curve B - A9N18412
Reliable 63A miniature circuit breaker for effective circuit protection.
Manufacturer part number: A9N18412
GTIN: 3606480379833
Availability: Out of stock
Only Ships to: France, Monaco For shipping outside these regions, please contact customer support.
This Schneider Electric Acti9 C120H is a low voltage multistandard miniature circuit breaker (MCB). It is a 2P circuit breaker with 2 protected poles, 63A rated current and B tripping curve. The rated short circuit breaking capacity goes up to 15000A at 230VAC to 400VAC conforming to EN/IEC 60898-1 standard and 15000A at 230VAC to 400VAC conforming to EN/IEC 60898-1 standard. This product complies with both industrial standard EN/IEC 60898-1 and residential standard EN/IEC 60947-2.Local signalling ON/OFF indication Mounting mode Clip-on Mounting support 35 mm symmetrical DIN rail Comb busbar and distribution block compatibility YES
