RS PRO Circular Connector, 5 Contacts, Flange Mount, Socket, Female, IP68 - 1444146

Durable RS PRO circular connector socket with 5 contacts, ideal for harsh environments with IP68 protection.
Manufacturer part number: 1444146
GTIN: 5056279053051
Vendor: YACHTNEEDS-RS
Availability: Out of stock
€30.63
i h
Only Ships to: France, Monaco
For shipping outside these regions, please contact customer support.
Number of Contacts = 5
Mounting Type = Flange Mount
Connector Size = Standard
Plug/Socket = Socket
Contact Gender = Female
Termination Method = Solder
IP Rating = IP68
Current Rating = 15A
Series = SP21
Voltage Rating = 500V
Mating Type = Threaded
Housing Material = Nylon 66, PC
Pole Format = 5P
Contact Plating = Gold
Maximum Operating Temperature = 85°C

2 Hole Flange Mount Plug and Socket 5A/15A/30A Circular Connectors (Threaded) IP68. From RS Pro, these threaded plug and sockets are serious contenders for your application. This particular model has a bigger and stronger shell complimented by its 2 hole flange-mounted connection. That coupled with the IP68 rating, makes sure that this industrial connector excels in harsh environments. When choosing a male or female connector, this version should really be one you consider. Features and Benefits. 5 way, 7 way, 9 way and 12 way available. Solder contact termination. High-quality Nylon66 shell. Panel hole cutout diameter: 21 mm
