RS PRO Circular Connector, 5 Contacts, Flange Mount, Socket, Female, IP68 - 1246679

Name: RS PRO Circular Connector, 5 Contacts, Flange Mount, Socket, Female, IP68 - 1246679
SKU: 1246679
Price: 34.15 EUR
Availability: OutOfStock

Durable RS PRO circular connector with 5 contacts, IP68 rated for reliable performance in harsh conditions.

Manufacturer part number: 1246679

GTIN: 5056279010559

Vendor: YACHTNEEDS-RS

Availability: Out of stock

€34.15

Qty:

i h

Only Ships to: France, Monaco

For shipping outside these regions, please contact customer support.

Number of Contacts = 5
Mounting Type = Flange Mount
Connector Size = Standard
Plug/Socket = Socket
Contact Gender = Female
Termination Method = Screw
IP Rating = IP68
Current Rating = 10A
Body Orientation = Straight
Voltage Rating = 500V
Mating Type = Threaded
Housing Material = Nylon 66, PC
Pole Format = 5P
Contact Plating = Gold
Maximum Operating Temperature = 85°C

2 Hole Flange Mount Socket 10A Circular Connectors (Threaded) IP68. From RS Pro, these threaded sockets are serious contenders for your application. This particular model has a bigger and stronger shell complimented by its 2 hole flange-mounted connection. That coupled with the IP68 rating, makes sure that this industrial connector excels in harsh environments. When choosing a female connector, this version should really be one you consider. Features ; Benefits. 2 way, 3 way and 5 way available Cable outer diameter acceptance: 4.5 mm - 7 mm Screw contact termination High-quality Nylon66 shell Panel hole cutout diameter: 21 mm
