RS PRO Circular Connector, 5 Contacts, Cable Mount, M12 Connector, Plug, Male, IP67 - 1246742

Number of Contacts = 5
Mounting Type = Cable Mount
Connector Size = M12
Plug/Socket = Plug
Contact Gender = Male
Termination Method = Solder
IP Rating = IP67
Current Rating = 5A
Body Orientation = Straight
Voltage Rating = 180V
Mating Type = Push-Pull
Housing Material = Chrome Plated Brass
Pole Format = 5P
Contact Plating = Gold
Contact Material = Brassmm

M12 Push-Pull Cable Plug. ;strong>DISCLAIMER: We have recently made a design change to the grip feature of this product and there will be a period of time where you may receive mixed stock. This will not affect the product performance. ;/strong>. From the trusted RS PRO brand, a selection of cable mount plugs designed for industrial applications. The IP67 connectors feature a push-pull mating mechanism providing a secure, watertight connection. With a knurled locking collar the cable mount plugs are easily mated and retained with panel sockets for semi-fixed applications. Alternatively, cable plugs can be mated with in-line cable sockets for cable to cable, quick connect and disconnect assemblies. The versatile RS PRO 12mm connectors can be used for both data and power connectivity. Features and Benefits. • IP67 ingress rating • Brass shell with a chrome plating • High-performance PPS insert • Gold plated brass contacts • Solder termination • -40 to + 85°C temperature range • 12 mm panel cut out • 4 to 6.5 mm or 4 to 8 mm cable acceptance range. Applications. The RS PRO series of 12mm cable plugs are generally used in industrial applications. The sturdy connectors are ideal for harsher environments that demand a tougher connection solution. Some of the most common areas are. • Test and measurement equipment • Medical equipment • Industrial automation • Instrumentation and lab equipment • Process control • Factory Automation • Marine equipment • Sensors and switches. Environment. The RS PRO 12mm Push-Pull series of connectors are waterproof and have an IP67 ingress rating. This means the connectors are fully sealed from dust and are protected from water jets and partial submersion for a limited time. FAQ. Q - How robust are the connectors? A – The RS Components 12mm circular connectors are manufactured from high-grade engineering materials. The plugs are extremely tough and specifically designed for harsh environments. Mating Parts. ; 124-6739 124-6739 mates with sockets ; 124-6696 124-6696 ; 124-6709 124-6709 ; 124-6740 124-6740 mates with sockets ; 124-6697 124-6697 ; 124-6706 124-6706 or ; 124-6710 124-6710 ; 124-6741 124-6741 mates with sockets ; 124-6698 124-6698 ; 124-6707 124-6707 or ; 124-6711 124-6711 ; 124-6742 124-6742 mates with sockets ; 124-6708 124-6708 or ; 124-6712 124-6712 ; 124-6743 124-6743 mates with socket ; 124-6700 124-6700 ; 124-6744 124-6744 mates with socket ; 124-6701 124-6701 ; 124-6745 124-6745 mates with socket ; 124-6703 124-6703 ; 124-6746 124-6746 mates with socket ; 124-6704 124-6704
