RS PRO 230 V 2 port Actuated Valve, 40 bars - 9108526
High-performance 230V actuated valve designed for industrial applications with a 40 bar pressure rating.
Manufacturer part number: 9108526
GTIN: 5056279165945
Only Ships to: France, Monaco For shipping outside these regions, please contact customer support.
WRAS approved, RoHS Compliant. Electric Actuator with s.31 Mini Valve. A range of RS Pro Electric Actuators with the s.31 mini valve. Features and Benefits. Strong construction Brass according to EN 12165 and EN 12164 specifications Chrome plated ball Dual sealing system for easy installation Blowout-proof brass stem PTFE self-lubricating seats Two FPM O-rings at the stem for maximum safety Compatible with most industrial fluids 100% Seal test guranteed in accordance to EN12266-1 RATE A in either direction EN 10226-1, ISO 228 parallel F/F threads Silicone free lubricant No metal on metal moving parts No maintenance Shell rating: 40 bar non-shock cold working pressure Seat rating: Delta P max permissible 16 bar Can also operate in vacuum line -20°C to 120°C temperature range. PED Directives. PED Directive 97/23, does not require CE marking in accordance with article 3, paragraph 3. Options. ISO 7/1, BS 21 BSPT taper threads NPT taper ANSI B.1.20.1 threads
