Key Features:
- Designed for one-sided accessibility, ideal for applications where access to the rear side is limited.
- Provides a stable internal thread in thin-walled components.
- Suitable for use in various materials, including metals and plastics.
- Allows for repeated screwing without compromising the integrity of the thread.
- Eliminates the need for rework, even on pre-coated parts.
Technical Specifications:
- Thread Size: M4, M5, M6, M8
- Grip Range: 0.5 mm to 3.0 mm
- Head Geometry:
- Small/flush head: Low push-out force
- Large flange: Very high push-out force
- Body Shape: Full hexagonal (Fullhex) for high spin-out resistance
- Material Options:
- Steel
- Stainless Steel A2
- Aluminum
- Surface Coatings: Available upon request, including options like Nycote and Precote
Materials:
- Manufactured from high-quality materials such as steel, stainless steel A2, and aluminum to ensure durability and corrosion resistance.
Dimensions:
- M4:
- Height: 10.5 mm
- Head Diameter: 6.58 to 6.88 mm
- Head Height: 0.67 mm
- Diameter: 5.89 mm
- Installation Length: 6.50 mm
- Pilot Hole Diameter: 6.00 mm
- M5:
- Height: 14.0 mm
- Head Diameter: 7.72 to 8.07 mm
- Head Height: 0.77 mm
- Diameter: 6.89 mm
- Installation Length: 9.00 mm
- Pilot Hole Diameter: 7.00 mm
- M6:
- Height: 16.0 mm
- Head Diameter: 9.75 to 10.10 mm
- Head Height: 0.87 mm
- Diameter: 8.89 mm
- Installation Length: 11.00 mm
- Pilot Hole Diameter: 9.00 mm
- M8:
- Height: 18.0 mm
- Head Diameter: 11.90 to 12.25 mm
- Head Height: 0.97 mm
- Diameter: 10.89 mm
- Installation Length: 12.50 mm
- Pilot Hole Diameter: 11.00 mm
Compatibility Information:
- Suitable for all materials, including metals and plastics.
- Ideal for applications requiring one-sided accessibility, such as hollow sections or components with undercuts.
- Compatible with standard hexagonal pilot holes.
Additional Details:
- Provides a reliable and efficient solution for creating internal threads in thin-walled components.
- Offers high spin-out resistance, especially in harder sheet metals.
- Available with various head diameters and heights to suit different application requirements.
