Omron Panel Mount Power Relay, 240V ac Coil, 25A Switching Current, DPST - G7L-2A-T AC100/120
Reliable Omron panel mount power relay with 25A switching capacity at 240V AC.
Manufacturer part number: G7L-2A-T AC100/120
GTIN: 4536853480820
Availability: Out of stock
Only Ships to: France, Monaco For shipping outside these regions, please contact customer support.
Coil Voltage = 240V ac
Contact Configuration = DPST
Mounting Type = Panel Mount
Switching Current = 25A
Number of Poles = 2
Latching = No
Terminal Type = Quick Connect
Maximum Switching Voltage AC = 250V
Maximum Switching Current AC = 25 A
Length = 52.5mm
Coil Resistance = 5.26 kO
Contact Material = Ag Alloy°C
Maximum Switching Power AC = 5.5 kVA
UL; CSA; TÜV. PCB Mounting ; Plug-in - Power Relays - G7L Series. Relay compatible with momentary voltage drops up to 50% of rated voltage High capacity and high dielectric strength Flame-resistance UL94V-0 insulation material Choice of connection types available - quick-connect or PCB terminals Suitable DIN rail/surface socket (Front connecting socket) and relay mounting clip (E-bracket) available separately for use with quick-connect types G7L-1A-T and G7L-2A-T (not to be used with G7L-1A-TUB and G7L-2A-TUB upper bracket mount types)
