Finder 39 Series Interface Relay, DIN Rail Mount, 110V ac/dc Coil, SPST - 39.21.0.125.0060
High-performance Finder 39 Series Interface Relay for reliable switching in compact DIN rail installations.
Manufacturer part number: 39.21.0.125.0060
Availability: Out of stock
Only Ships to: France, Monaco For shipping outside these regions, please contact customer support.
Coil Voltage = 110V ac/dc
Contact Configuration = SPST
Mounting Type = DIN Rail
Series = 39 Series
Minimum Input Voltage = 88V
Terminal Type = Screw
Depth = 90.7mm
Height = 87mm
Length = 6.2mm
Contact Material = Silver Alloy
Input Current = 5.6mA
Standards Met = CE, cULus, EAC, EN 60715, PCT, RINA, SA, UL, VDE°C
39 Series - EMR Screw Terminals. A range of electromechanical relay interface modules from the 39 series from Finder, these relays have a high switching capability. Space saving 6.2 mm wide Connections for 16-way jumper link Integral coil indication and protection circuit Secure retention and easy ejection by plastic clip Dual screw head (blade+cross) terminals 35 mm DIN rail mounting
