Festo G 3/4 Pneumatic Regulator - 0.5bar to 12bar, 16bar max. input, 192361 - LR-3/4-D-O-DI-MAXI
Achieve precise pressure control with the Festo G 3/4 Pneumatic Regulator, designed for reliable performance.
Manufacturer part number: LR-3/4-D-O-DI-MAXI
GTIN: 4052568150976
Availability: Out of stock
Only Ships to: France, Monaco For shipping outside these regions, please contact customer support.
Port Connection = G 3/4
Maximum Outlet Pressure = 12bar
Minimum Outlet Pressure = 0.5bar
Maximum Input Pressure = 16bar
Manufacturer Series = D
Typical Flow Rate = 6800L/min
Model Number p = 192361
The Festo D series pressure regulator has a G 3/4 pneumatic port connecting thread. It is a directly-controlled diaphragm regulator design structure without pressure gauge. The regulator has a working pressure up to 12 bar.Size = maxi Actuator lock = rotary knob with lock Assembly position = any
