Festo G 1/8 Pneumatic Regulator - 0.5bar to 12bar, 1/8 in, 16bar max. input, 162590 - LR-1/8-D-O-MINI
Achieve precise pressure control with the Festo G 1/8 Pneumatic Regulator, designed for reliable performance.
Manufacturer part number: LR-1/8-D-O-MINI
GTIN: 4052568072209
Availability: Out of stock
Only Ships to: France, Monaco For shipping outside these regions, please contact customer support.
Port Connection = G 1/8
Maximum Outlet Pressure = 12bar
Minimum Outlet Pressure = 0.5bar
Maximum Input Pressure = 16bar
Manufacturer Series = D
Pressure Gauge Port Size = G 1/8
Port Connection Thread Size = 1/8 in
Pressure Gauge Port Thread Size = 1/8 in
Typical Flow Rate = 800L/min
Port Connection Thread Standard = G
Minimum Operating Temperature = -10°C
Model Number p = 162590mm
The Festo D series pressure regulator has a G1/8 pneumatic port connecting thread. It is a directly-controlled diaphragm regulator design structure without pressure gauge. The regulator has a working pressure up to 12 bar.Size = mini Actuator lock = rotary knob with lock Assembly position = any
