Festo G 1/4 Pneumatic Regulator - 0.5bar to 7bar, 1/4 in, 16bar max. input, 194614 - LRS-1/4-D-7-MINI

Port Connection = G 1/4
Maximum Outlet Pressure = 7bar
Minimum Outlet Pressure = 0.5bar
Maximum Input Pressure = 16bar
Manufacturer Series = D
Pressure Gauge Port Size = G 1/4
Port Connection Thread Size = 1/4 in
Pressure Gauge Port Thread Size = 1/4 in
Typical Flow Rate = 1600L/min
Port Connection Thread Standard = G
Minimum Operating Temperature = -10°C
Maximum Operating Temperature = +60°C
Overall Height = 95mm

Festo Pneumatic Regulator, 0.5 Bar to 7 Bar, G 1/4 - D Series - LRS-1/4-D-7-MINI This pneumatic regulator from Festo controls pressure in compressed air applications. Its modular design makes it compatible with all the other service units in Festos D series of industrial air-preparation components. For additional peace of mind, the unit has a lockable head that means only authorised staff can alter its pressure settings. It has low hysteresis, so it maintains consistent performance regardless of fluctuations in system pressure. This allows the regulator to instantly react and respond to changes in air pressure, which improves its overall efficiency. This unit offers a choice of different fitting options, thanks to its two pressure-gauge connections. Theres no need to worry about leakage or mounting misalignment, as the regulators through-bolt joining system uses only one compression seal between units. This allows for simple yet highly stable assembly, even in harsh industrial applications.• Fast typical flow rate of 1600 L/min for improved system reliability • Simple and rugged design for a long working life • Streamlined exterior thats easy to keep clean • Vibration-proof regulator knob for improved safety • Conveniently supplied with a pressure gauge and mounting accessories
