ABB Electronic Circuit Breaker 4A 24V EPD24, DIN Rail Mount - 2CDE601101R2004 EPD24-TB-101-4A
Ensure reliable overcurrent protection for your 24V DC circuits with ABB's EPD24 electronic circuit breaker.
Manufacturer part number: 2CDE601101R2004 EPD24-TB-101-4A
Only Ships to: France, Monaco For shipping outside these regions, please contact customer support.
Series = EPD24
Current Rating = 4A
Rated DC Voltage = 24V
Mounting Style = DIN Rail Mount
EPD24 Series Electronic Protection Device. ABB EPD24 series electronic protection devices offer overcurrent protection for 24 V dc load circuits. This protection is achieved by a combination of active electronic current limitations. In the case of a short circuit and an overload, deactivation from 1.1 x Input occurs. If a fault occurs in a load circuit, the EPD24 protection device will detect this rapidly and reliably, disable the power output transistor, interrupting the current flow in the defective circuit. The maximum possible overcurrent is always limited to 1.3…1.8 times the selected rated current. An activation of capacitive loads up to 20,000 µF is possible, deactivation only occurring in the case of overloads or short circuits. Selective load protection Reliable overload disconnection with 1.1 x Input plus Manual ON/OFF button Clear status and failure indication through LED and integrated auxiliary contact Integral fail-safe element adjusted to current rating Width per unit only 12.5 mm DIN rail mounting Easy wiring through busbar LINE+ and 0 V as well as signal bars
